ASTM A335 Grade P22, commonly known in the industry as 2 ¼ Chrome, is a Seamless Ferritic Alloy-Steel P22 Pipe specifically engineered for high-temperature and high-pressure service. Identified by the UNS designation K21590, the ASTM A335 P22 Pipe Specification covers both nominal and minimum wall thicknesses. It is an essential material for critical industrial systems operating at temperatures exceeding 540°C, where standard carbon steel lacks the necessary structural integrity.
The unusual performance of ASTM A335 Grade P22 Alloy Pipe is prompted by its specific chemical make up which is mainly characterized by introduction of Chromium and Molybdenum. Chromium enhances strength in the high temperature, oxidation resistance and increases tensile and yield strength at room temperature. Molybdenum is used to improve the elastic limit and hardenability as well as being the most efficient additive to boost the high-temperature creep resistance. This alloy ensures that the SA 335 P22 chrome moly pipe is very resistant to pitting corrosion and minimizes the tendencies to embrittlement that high chromium levels have.
In terms of mechanical performance, Alloy Steel P22 Pipes provide a robust balance of strength and durability. These pipes maintain a minimum tensile strength of 415 MPa and a minimum yield strength of 205 MPa, along with an elongation capacity of approximately 30%. These properties allow a335 p22 Pipes to withstand thermal cycling and pressure fluctuations in aggressive media. Furthermore, the material is highly versatile, offering excellent weldability and formability for complex operations such as bending, flanging, and vanstoning.
The manufacturing process for ASTM A335 Grade P22 Alloy Steel Seamless Pipe involves either hot finishing or cold drawing, followed by rigorous heat treatments. These treatments may include full or isothermal annealing, quenching, or normalizing and tempering to achieve the necessary mechanical stability. Because of its durability, the P22 Boiler Pipe is a primary choice for high-pressure steam pipelines in power generation. It is equally vital in refineries, petrochemical plants, and heavy industrial applications like heat exchangers and offshore oil drilling.
Solitaire Overseas stands as a world-class supplier specializing in Chrome Alloy piping solutions. We maintain one of the industry's largest inventories of a335 p22 high energy pipes, heater tubes, fittings, flanges, and valves. Our stock encompasses a wide range from ½” NPS to 30” NPS, with wall thicknesses starting at STD and reaching up to 4” thick. We also provide material certified to ASTM/ASME A/SA 213 to meet the specialized equipment designs of modern power plants. Our commitment at Solitaire Overseas is to foster strong partnerships with our clients by offering expert technical support and highly competitive pricing for all high-pressure piping requirements.
Check price of Alloy Steel T1 Tubes, Alloy Steel T2 Tubes & Alloy Steel T5 Tubes
| Specification | Details |
|---|---|
| Grade | P22 |
| UNS | K21590 |
| Thickness | 2.0 to 14 mm |
| Outer Dimensions (O.D.) | 19.05 to 114.3 mm |
| Size of SA335 P22 Boiler Pipes (in Inch) | 1/2 to 36” NB |
| Available Length | 16000 mm or custom length |
| Schedule Chart | Schedule 20 to SCH XXS (heavier wt on request) up to 280 mm thickness |
| Shapes | Round, Rect., Square, Hydraulic or custom |
| Standard Specification | ASTM A335 P22 and ASME SA 335 Grade P22 (with IBR Certificates) |
| Schedule | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| P22 material | European, Japanese, Korean, USA, Russia, Indian (We don't stock China Material) |
| Tolerance chart | Cold drawn P22 Pipes: +/-0.1mm Cold rolled P22 Pipes: +/-0.05mm |
| Manufacturing Process of P22 Pipes | Cold rolled, Cold drawn, Cold finished, hot rolled |
| Types | Seamless, EFW, ERW, Fabricated, Welded |
| Length | Single Random (18 - 25 feet), Double Random (38 - 40 feet) & Cut to length as required |
| End | Plain End, threaded and coupled, Beveled End, Treaded |
| Carbon, % | P, % | Mo, % | Mn, % | Si, % | S, % | Cr, % |
|---|---|---|---|---|---|---|
| 00.015 max | 00.025 max | 00.87-1.13 | 00.30-0.61 | 00.50 max | 00.025 max | 1.90-2.60 |
| Tensile Stress, MPa | Yield Stress, MPa | Elongation, % |
|---|---|---|
| 415 MPa minimum | 205 MPa minimum | 30 minimum |
| American Society of Mechanical Engineers | British Standard | American Society for Testing and Materials | International Organization for Standardization | Deutsches Institut für Normung | American Bureau of Shipping | Japanese Industrial Standards G 3458 | LRS | Unified Numbering System |
|---|---|---|---|---|---|---|---|---|
| SA335 P22 | 3604 P1 622 | A335 P22 | 2604 II TS34 | 17175 10CrMo910 | ABS 13 | STPA 24 | Sec 2 2-1/4Cr1Mo410 | K21590 |
| Grade | Heat Treatment Type | Normalizing Temperature Range F [C] | Subcritical Annealing or Tempering Temperature Range F [C] |
|---|---|---|---|
| P22 | Full or isothermal Anneal | ||
| Normalize and Temper | ***** | 1250 [675] |
| Calculated Minimum Elongation Values | |||||
|---|---|---|---|---|---|
| Elongation in 2 in. or 50 mm, min % | |||||
| Wall Thickness | P5, P9, P11, P22 | P91 | |||
| in. | mm | Longitudinal | Transverse | Longitudinal | |
| 5/16 (0.312) | 8 | 30 | 20 | 20 | |
| 9/32 (0.281) | 7.2 | 28 | 19 | 19 | |
| 1/4 (0.250) | 6.4 | 27 | 18 | 18 | |
| 7/32 (0.219) | 5.6 | 26 | 17 | ||
| 3/16 (0.188) | 4.8 | 24 | 16 | ||
| 5/32 (0.156) | 4 | 22 | 15 | ||
| 7/8 (0.125) | 3.2 | 21 | 14 | ||
| 3/32 (0.094) | 2.4 | 20 | 13 | ||
| 1/18 (0.062) | 1.6 | 18 | 12 | ||
| Size in inch | 5S | S10 | S20 | S40 | S60 | S80 | S120 | S100 | S140 | S160 |
|---|---|---|---|---|---|---|---|---|---|---|
| mm | ||||||||||
| 1/2 | 1.7 | 2.77 | 3.73 | 4.78 | ||||||
| 1 1/4 | 1.7 | 3.56 | 4.85 | 6.35 | ||||||
| 3/4 | 1.7 | 2.87 | 3.91 | 5.56 | ||||||
| 1 | 1.7 | 3.38 | 4.55 | 6.35 | ||||||
| 2 | 1.7 | 3.91 | 5.54 | 9.74 | ||||||
| 1 1/2 | 1.7 | 3.68 | 5.08 | 7.14 | ||||||
| 4 | 2.1 | 6.02 | 8.56 | 11.1 | 13.5 | |||||
| 5 | 2.8 | 6.55 | 9.53 | 12.7 | 15.9 | |||||
| 10 | 3.4 | 6.4 | 9.27 | 12.7 | 15.1 | 21.4 | 19.3 | 25.4 | 28.6 | |
| 12 | 4 | 6.4 | 10.3 | 14.3 | 17.5 | 25.4 | 21.4 | 28.6 | 33.3 | |
| 18 | 4.2 | 6.4 | 7.9 | 14.3 | 19.1 | 23.8 | 34.9 | 29.4 | 39.7 | 45.2 |
| 20 | 4.8 | 6.4 | 9.5 | 15.1 | 20.6 | 26.2 | 38.1 | 32.5 | 44.5 | 50 |
| 26 | 7.9 | 13 | ||||||||
| 28 | 7.9 | 13 | ||||||||
| 34 | 7.9 | 13 | 17.5 | |||||||
| 36 | 7.9 | 13 | 19.1 |
| O.D. x Thickness(mm) | O.D x Thickness(mm) | O.D x Thickness(mm) |
|---|---|---|
| 38.1 x 3.2 | 57.0 x 4.9 | 76.2 x 4.0 |
| 38.1 x 4.0 | 57.0 x 6.3 | 76.2 x 5.0 |
| 38.1 x 6.3 | 57.0 x 7.9 | 76.2 x 6.3 |
| 42.4 x 3.2 | 60.3 x 3.2 | 82.5 x 4.5 |
| 42.4 x 4.0 | 60.3 x 3.6 | 88.9 x 3.2 |
| 44.5 x 3.2 | 60.3 x 5.0 | 88.9 x 3.6 |
| 44.5 x 6.3 | 63.5 x 3.2 | 88.9 x 4.0 |
| 48.3 x 3.2 | 63.5 x 3.6 | 101.6 x 3.6 |
| 48.3 x 3.6 | 63.5 x 4.0 | 101.6 x 4.5 |
| 50.8 x 4.5 | 63.5 x 6.3 | 101.6 x 6.3 |
| 51.0 x 3.2 | 63.5 x 7.9 | 114.3 x 3.6 |
| 51.0 x 3.6 | 70.0 x 3.2 | 114.3 x 5.0 |
| 51.0 x 6.3 | 70.0 x 3.6 | 139.7 x 4.0 |
| 57.0 x 3.2 | 70.0 x 6.3 | 139.7 x 5.0 |
| 57.0 x 3.6 | 76.2 x 3.6 | 139.7 x 6.3 |
| NB | Size | OD | 40S | 5S | 10S | S10 | S20 | S40 | S60 | XS/80S | S80 | S100 | S120 | S140 | S160 | XXS |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | ||
| 1/8 | 10.29 | 1.2 | 1.73 | 2.41 | ||||||||||||
| 1/4 | 13.72 | 1.7 | 2.24 | 3.02 | ||||||||||||
| 3/8 | 17.15 | 1.7 | 2.31 | 3.2 | ||||||||||||
| 15 | 1/2 | 21.34 | 2.8 | 1.7 | 2.1 | 2.77 | 3.73 | 3.73 | 4.78 | 7.47 | ||||||
| 20 | 3/4 | 26.67 | 2.9 | 1.7 | 2.1 | 2.87 | 3.91 | 3.91 | 5.56 | 7.82 | ||||||
| 25 | 1 | 33.4 | 3.4 | 1.7 | 2.8 | 3.38 | 4.55 | 4.55 | 6.35 | 9.09 | ||||||
| 32 | 1 1/4 | 42.16 | 3.6 | 1.7 | 2.8 | 3.56 | 4.85 | 4.85 | 6.35 | 9.7 | ||||||
| 40 | 1 1/2 | 48.26 | 3.7 | 1.7 | 2.8 | 3.68 | 5.08 | 5.08 | 7.14 | 10.2 | ||||||
| 50 | 2 | 60.33 | 3.9 | 1.7 | 2.8 | 3.91 | 5.54 | 5.54 | 9.74 | 11.1 | ||||||
| 65 | 2 1/2 | 73.03 | 5.2 | 2.1 | 3.1 | 5.16 | 7.01 | 7.01 | 9.53 | 14 | ||||||
| 80 | 3 | 88.9 | 5.5 | 2.1 | 3.1 | 5.49 | 7.62 | 7.62 | 11.1 | 15.2 | ||||||
| 90 | 3 1/2 | 101.6 | 5.7 | 2.1 | 3.1 | 5.74 | 8.08 | 8.08 | ||||||||
| 100 | 4 | 114.3 | 6 | 2.1 | 3.1 | 6.02 | 8.56 | 8.56 | 11.1 | 13.5 | 17.1 | |||||
| 125 | 5 | 141.3 | 6.6 | 2.8 | 3.4 | 6.55 | 9.53 | 9.53 | 12.7 | 15.9 | 19.1 | |||||
| 150 | 6 | 168.3 | 7.1 | 2.8 | 3.4 | 7.11 | 10.97 | 11 | 14.3 | 18.3 | 22 | |||||
| 200 | 8 | 219.1 | 8.2 | 2.8 | 3.8 | 6.4 | 8.18 | 10.3 | 12.7 | 12.7 | 15.1 | 19.3 | 20.6 | 23 | 22.2 | |
| 250 | 10 | 273.1 | 9.3 | 3.4 | 4.2 | 6.4 | 9.27 | 12.7 | 12.7 | 15.1 | 19.3 | 21.4 | 25.4 | 28.6 | 25.4 | |
| 300 | 12 | 323.9 | 9.5 | 4 | 4.6 | 6.4 | 10.3 | 14.3 | 12.7 | 17.5 | 21.4 | 25.4 | 28.6 | 33.3 | 25.4 | |
| 350 | 14 | 355.6 | 9.5 | 4 | 4.8 | 6.4 | 7.9 | 11.1 | 15.1 | 12.7 | 19.1 | 23.8 | 27.8 | 31.8 | 35.7 | |
| 400 | 16 | 406.4 | 9.5 | 4.2 | 4.8 | 6.4 | 7.9 | 12.7 | 16.7 | 12.7 | 21.4 | 26.2 | 31 | 36.5 | 40.5 | |
| 450 | 18 | 457.2 | 9.5 | 4.2 | 4.8 | 6.4 | 7.9 | 14.3 | 19.1 | 12.7 | 23.8 | 29.4 | 34.9 | 39.7 | 45.2 | |
| 500 | 20 | 508 | 9.5 | 4.8 | 5.5 | 6.4 | 9.5 | 15.1 | 20.6 | 12.7 | 26.2 | 32.5 | 38.1 | 44.5 | 50 | |
| 550 | 22 | 558.8 | 9.5 | 4.8 | 5.5 | 6.4 | 9.5 | 22.2 | 12.7 | 28.6 | 34.9 | 41.3 | 47.6 | 54 | ||
| 600 | 24 | 609.6 | 9.5 | 5.5 | 6.4 | 6.4 | 9.5 | 17.5 | 24.6 | 12.7 | 31 | 38.9 | 46 | 52.4 | 59.5 | |
| 650 | 26 | 660.4 | 9.5 | 7.9 | 13 | 12.7 | ||||||||||
| 700 | 28 | 711.2 | 9.5 | 7.9 | 13 | 12.7 | ||||||||||
| 750 | 30 | 762 | 9.5 | 6.4 | 7.9 | 7.9 | 13 | 12.7 | ||||||||
| 800 | 32 | 812.8 | 9.5 | 7.9 | 13 | 17.5 | 12.7 | |||||||||
| 850 | 34 | 863.6 | 9.5 | 7.9 | 13 | 17.5 | 12.7 | |||||||||
| 900 | 36 | 914.4 | 9.5 | 7.9 | 13 | 19.1 | 12.7 |
| Surface Finishes | Bare, Mill Varnish, Oiled, Galv, FBE Dual, FBE, 3LPE, Coal Tar, 3LPP, Concrete Coating and Tape Wrap. |
|---|---|
| End Finishes | Square Cut, Beveled, Threaded & Coupled. |
| ASTM A450 | Hot rolled | Outside Diameter, mm | Tolerance, mm |
| Outer Diameter≤101.6 | +0.4/-0.8 | ||
| 101.6<Outer Diameter≤190.5 | +0.4/-1.2 | ||
| 190.5<Outer Diameter≤228.6 | +0.4/-1.6 | ||
| Cold Drawn | Outside Diameter, mm | Tolerance, mm | |
| Outer Diameter<25.4 | ±0.10 | ||
| 25.4≤Outer Diameter≤38.1 | ±0.15 | ||
| 38.1<Outer Diameter<50.8 | ±0.20 | ||
| 50.8≤Outer Diameter<63.5 | ±0.25 | ||
| 63.5≤Outer Diameter<76.2 | ±0.30 | ||
| 76.2≤Outer Diameter≤101.6 | ±0.38 | ||
| 101.6<Outer Diameter≤190.5 | +0.38/-0.64 | ||
| 190.5<Outer Diameter≤228.6 | +0.38/-1.14 | ||
| ASTM A530 & ASTM A335 | NPS | Outside Diameter, inch | Tolerance, mm |
| 1/8≤Outer Diameter≤1-1/2 | ±0.40 | ||
| 1-1/2<Outer Diameter≤4 | ±0.79 | ||
| 4<Outer Diameter≤8 | +1.59/-0.79 | ||
| 8<Outer Diameter≤12 | +2.38/-0.79 | ||
| Outer Diameter>12 | ±1% |
| Outer Diameter * Thickness in MM | Outer Diameter * Thickness in MM | Outer Diameter * Thickness in MM |
|---|---|---|
| 38.1 * 3.2 | 57.0 * 4.9 | 76.2 * 4.0 |
| 38.1 * 4.0 | 57.0 * 6.3 | 76.2 * 5.0 |
| 38.1 * 6.3 | 57.0 * 7.9 | 76.2 * 6.3 |
| 42.4 * 3.2 | 60.3 * 3.2 | 82.5 * 4.5 |
| 42.4 * 4.0 | 60.3 * 3.6 | 88.9 * 3.2 |
| 44.5 * 3.2 | 60.3 * 5.0 | 88.9 * 3.6 |
| 44.5 * 6.3 | 63.5 * 3.2 | 88.9 * 4.0 |
| 48.3 * 3.2 | 63.5 * 3.6 | 101.6 * 3.6 |
| 48.3 * 3.6 | 63.5 * 4.0 | 101.6 * 4.5 |
| 50.8 * 4.5 | 63.5 * 6.3 | 101.6 * 6.3 |
| 51.0 * 3.2 | 63.5 * 7.9 | 114.3 * 3.6 |
| 51.0 * 3.6 | 70.0 * 3.2 | 114.3 * 5.0 |
| 51.0 * 6.3 | 70.0 * 3.6 | 139.7 * 4.0 |
| 57.0 * 3.2 | 70.0 * 6.3 | 139.7 * 5.0 |
| 57.0 * 3.6 | 76.2 * 3.6 | 139.7 * 6.3 |
To ensure the structural integrity of ASTM A335 P22, specific thermal cycles and welding methods must be strictly followed:
For high-pressure applications, the following process-filler combinations are utilized:
| Welding Process | Specified Filler Metal / Consumable |
|---|---|
| TIG (Tungsten Inert Gas) | Union | CrMo 910 |
| SAW (Submerged Arc) | Union S1CrMo2 / UV 420 TTR |
| MAG (Massive Wire) | Union | CrMo 910 |
| Arc Welding (Manual) | Phoenix SH Chromium 2KS |
| MAG (Cored Wire) | Union MV CrMo - M21 |
Due to its excellent creep resistance and high-temperature strength, P22 is the industry standard for:
Call us today to learn more about our Chrome Moly Alloy Seamless P22 Pipe inventory.
Fill out the form below or email vishal@solitaire-overseas.com for a fast, no-obligation quote on any Alloy Seamless P22 Pipe
Contact UsASTM A335 Grade P22 is a low-alloy carbon steel enhanced with chromium and molybdenum. These additives improve the metal’s hardness and strength, allowing it to resist oxidation and maintain its structural integrity even in extreme heat.
The main difference lies in the chemical makeup; P22 contains higher levels of chromium and molybdenum than P11. This richer alloy composition gives P22 superior performance and durability in high-temperature industrial environments.
P22 grade material is recognized globally and corresponds to several international standards. Common equivalents include EN 10216-2, ASTM/ASME A213 (tubing), GOST 550-75, and NBR 5603.
A335 P22 typically has a maximum hardness value of 163 HB. Despite its strength, the material remains highly ductile, making it easy to manufacture into various shapes like round, rectangular, or hydraulic pipes.
These pipes are built for extreme service and can operate continuously at temperatures ranging between 590°C and 600°C. Their high-temperature performance is further enhanced through specialized heat treatments like normalizing and tempering.
| Size NPS | I.D. | Pipe O.D. | Standard Wall Thickness | Weight per Foot | Standard as per XXHY | Schedule Chart | Pipe Volume Gallon Capacity Per FT | Section Modulus |
|---|---|---|---|---|---|---|---|---|
| 1/2 | 0.622 | 0.84 | 0.109 | 0.85 | STD | 40 | .0158 | .0407 |
| 0.546 | 0.147 | 1.09 | XHY | 80 | .0122 | .0478 | ||
| 0.464 | 0.188 | 1.31 | 160 | .0088 | .0528 | |||
| 0.252 | 0.294 | 1.72 | XXHY | .0026 | .0577 | |||
| 3/4 | 0.824 | 1.05 | 0.113 | 1.13 | STD | 40 | .0277 | .0705 |
| 0.742 | 0.154 | 1.48 | XHY | 80 | .0225 | .0853 | ||
| 0.612 | 0.219 | 1.95 | 160 | .0153 | .1006 | |||
| 0.434 | 0.308 | 2.44 | XXHY | .0077 | .1103 | |||
| 1 | 1.049 | 1.315 | 0.133 | 1.68 | STD | 40 | .0449 | .1328 |
| 0.957 | 0.179 | 2.17 | XHY | 80 | .0374 | .1606 | ||
| 0.815 | 0.250 | 2.85 | 160 | .0271 | .1904 | |||
| 0.599 | 0.358 | 3.66 | XXHY | .0146 | .2136 | |||
| 1 1/4 | 1.380 | 1.66 | 0.140 | 2.27 | STD | 40 | .0777 | .2346 |
| 1.278 | 0.191 | 3.00 | XHY | 80 | .0666 | .2913 | ||
| 1.160 | 0.250 | 3.77 | 160 | .0549 | .3421 | |||
| 0.896 | 0.382 | 5.22 | .0328 | .4110 | ||||
| 1 1/2 | 1.610 | 1.90 | 0.145 | 2.72 | STD | 40 | .1058 | .3262 |
| 1.500 | 0.200 | 3.63 | XHY | 80 | .0918 | .4118 | ||
| 1.338 | 0.281 | 4.86 | 160 | .0730 | .5079 | |||
| 1.100 | 0.400 | 6.41 | .0494 | .5977 | ||||
| 2 | 2.157 | 2.375 | 0.109 | 2.64 | 10 | .1898 | .4205 | |
| 2.067 | 0.154 | 3.66 | STD | 40 | .1743 | .5606 | ||
| 1.939 | 0.218 | 5.03 | XHY | 80 | .1534 | .7309 | ||
| 1.875 | 0.250 | 5.68 | .1434 | .8045 | ||||
| 1.813 | 0.281 | 6.29 | .1344 | .8666 | ||||
| 1.687 | 0.344 | 7.47 | 160 | .1161 | .9806 | |||
| 1.503 | 0.436 | 9.04 | XXHY | .0922 | 1.1043 | |||
| 2 1/2 | 2.635 | 2.875 | 0.120 | 3.53 | 10 | .2833 | .6870 | |
| 2.469 | 0.203 | 5.80 | STD. | 40 | .2487 | 1.0640 | ||
| 2.443 | 0.216 | 6.14 | .2435 | 1.1169 | ||||
| 2.375 | 0.250 | 7.02 | .2301 | 1.2468 | ||||
| 2.323 | 0.276 | 7.67 | XHY | 80 | .2202 | 1.3386 | ||
| 2.125 | 0.375 | 10.02 | 160 | .1842 | 1.6371 | |||
| 1.771 | 0.552 | 13.71 | XXXHY | .1280 | 1.9971 | |||
| 3 | 3.260 | 3.50 | 0.120 | 4.34 | .4336 | 1.0411 | ||
| 3.188 | 0.156 | 5.58 | .4147 | 1.3122 | ||||
| 3.156 | 0.172 | 6.12 | .4064 | 1.4265 | ||||
| 3.124 | 0.188 | 6.66 | .3984 | 1.5342 | ||||
| 3.068 | 0.216 | 7.58 | STD. | 40 | .3840 | 1.7241 | ||
| 3.000 | 0.250 | 8.69 | .3672 | 1.9372 | ||||
| 2.938 | 0.281 | 9.67 | .3521 | 2.1207 | ||||
| 2.900 | 0.300 | 10.26 | XHY | 80 | .3431 | 2.2253 | ||
| 2.624 | 0.438 | 14.34 | 160 | .2811 | 2.8774 | |||
| 2.300 | 0.600 | 18.6 | XXHY | .2158 | 3.4243 | |||
| 3 1/2 | 3.760 | 4.0 | 0.120 | 4.98 | 10 | .5768 | 1.3776 | |
| 3.548 | 0.226 | 9.12 | STD. | 140 | .5136 | 2.3939 | ||
| 3.500 | 0.250 | 10.02 | .4998 | 2.6001 | ||||
| 3.438 | 0.281 | 11.17 | .4821 | 2.8562 | ||||
| 3.364 | 0.318 | 12.52 | XHY | 80 | .4617 | 3.1400 | ||
| 2..728 | 0.636 | 22.87 | XXHY | .3085 | 4.8795 | |||
| 4 | 4.260 | 4.5 | 0.120 | 5.62 | 10 | .7404 | 1.7612 | |
| 4.188 | 0.156 | 7.24 | .7156 | 2.2354 | ||||
| 4.124 | 0.188 | 8.67 | .6942 | 2.6296 | ||||
| 4.094 | 0.203 | 9.32 | .6838 | 2.8173 | ||||
| 4.062 | 0.219 | 10.02 | .6725 | 3.0184 | ||||
| 4.026 | 0.237 | 10.80 | STD. | 40 | .6613 | 3.2145 | ||
| 4.000 | 0.250 | 11.36 | .6528 | 3.3611 | ||||
| 3.938 | 0.281 | 12.67 | 60 | .6326 | 3.7021 | |||
| 3.876 | 0.312 | 13.97 | .6126 | 4.0273 | ||||
| 3.826 | 0.337 | 15.00 | XHY | 80 | .5972 | 4.2713 | ||
| 3.624 | 0.438 | 19.02 | 120 | .5361 | 5.1790 | |||
| 3.438 | 0.531 | 22.53 | 160 | .4822 | 5.8997 | |||
| 3.152 | 0.674 | 27.57 | XXHY | .4054 | 6.7927 | |||
| 5 | 5.187 | 5.563 | 0.188 | 10.80 | 1.0979 | 4.1161 | ||
| 5.125 | 0.219 | 12.51 | 1.0716 | 4.7279 | ||||
| 5.047 | 0.258 | 14.63 | STD. | 40 | 1.0391 | 5.4500 | ||
| 5.001 | 0.281 | 15.87 | 1.0204 | 5.8644 | ||||
| 4.939 | 0.312 | 17.51 | .99647 | 6.4074 | ||||
| 4.875 | 0.344 | 19.19 | .9696 | 6.9358 | ||||
| 4.813 | 0.375 | 20.80 | XHY | 80 | .9449 | 7.4300 | ||
| 4.563 | 0.500 | 27.06 | 120 | .8495 | 9.2534 | |||
| 4.313 | 0.625 | 32.99 | 160 | .7590 | 10.7976 | |||
| 4.063 | 0.750 | 38.59 | XXHY | .6734 | 12.0954 | |||
| 6 | 6.407 | 6.625 | 0.109 | 7.59 | 5 | 1.6748 | 3.5769 | |
| 6.357 | 0.134 | 9.30 | 10 | 1.6488 | 4.3475 | |||
| 6.313 | 0.156 | 10.79 | 1.6260 | 5.0107 | ||||
| 6.249 | 0.188 | 12.94 | 1.5937 | 5.9351 | ||||
| 6.219 | 0.203 | 13.94 | 1.5780 | 6.3804 | ||||
| 6.187 | 0.219 | 15.00 | 1.5620 | 6.8261 | ||||
| 6.125 | 0.250 | 17.04 | 1.5306 | 7.6905 | ||||
| 6.065 | 0.280 | 18.99 | STD. | 40 | 1.5008 | 8.4958 | ||
| 6.001 | 0.312 | 21.06 | 1.4688 | 9.3416 | ||||
| 5.937 | 0.344 | 23.10 | 1.4391 | 10.111 | ||||
| 5.875 | 0.375 | 25.05 | 1.4082 | 10.893 | ||||
| 5.761 | 0.432 | 28.60 | XHY | 80 | 1.3541 | 12.224 | ||
| 5.625 | 0.500 | 32.74 | 1.2909 | 13.711 | ||||
| 5.501 | 0.562 | 36.43 | 120 | 1.2346 | 14.9806 | |||
| 5.375 | 0.625 | 40.09 | 1.1787 | 16.1821 | ||||
| 5.187 | 0.719 | 45.39 | 160 | 1.0977 | 17.8243 | |||
| 4.897 | 0.864 | 53.21 | XXHY | .9784 | 20.025 | |||
| 4.625 | 1.000 | 60.13 | .8727 | 21.7719 | ||||
| 4.375 | 1.125 | 66.14 | .7809 | 23.1237 |
