ASTM A213 Grade T5 Alloy Steel Seamless Tubes Supplier

Q: What are the benefits of ASTM A213 T5 Tubes?

ASTM A213 T5 tubes offer several advantages for demanding applications, including high-temperature strength. They can be welded using specialized techniques to create reliable joints and have improved corrosion resistance compared to regular steel, which helps them withstand harsh environments found in power plants, refineries, and chemical facilities.

Q: What are the limitations of ASTM A213 T5 Tubes?

There are some factors to consider with T5 tubes, including cost. T5 tubes are typically more expensive than regular steel tubes due to their specialized properties. Additionally, welding T5 tubes requires specific skills and expertise to ensure proper joint integrity.

Alloy Steel T5 Tubes, Alloy Steel T5 Seamless Tubing, Chromium Molybdenum Steel T5 Tubes and ASTM A213 Chrome Moly T5 Tube, Manufacturer, Supplier and Exporter in India

As a leading supplier and stockholder of ASTM A213 Grade T5 Tubing in India, we specialize in providing high-quality alloy steel T5 tubes for demanding high-pressure and high-temperature services. These tubes are known for their exceptional toughness, strength, and superior performance in critical applications like heat exchangers, superheaters, and boilers. Also known as chrome moly tubes, their composition of chromium (Cr) and molybdenum (Mo) gives them excellent resistance to corrosion and oxidation, making them highly durable in harsh environments. We offer a wide range of seamless and welded tubes, including forms such as Electric Fusion Welded (EFW) and Electric Resistance Welded (ERW), in various shapes and custom sizes to meet diverse industrial needs with on-time delivery and at an affordable price.

ASTM A213 T5 is a ferritic alloy steel highly valued for its heat resistance and mechanical integrity at elevated temperatures. The addition of chromium (4.00-6.00%) provides significant oxidation and corrosion resistance, while molybdenum (0.45-0.65%) enhances tensile strength and creep resistance. The material's properties are carefully controlled through specific heat treatments and forming processes. For instance, major hot working of the tubes should be performed between 2300°F and 1850°F to maintain structural integrity, while cold working at levels between 30% and 65% is effective for achieving high room-temperature yield strength.

Enquire Now

ASTM A213 T5 Alloy Steel Seamless Tubes Specifications
Alloy T5 Tubes Equivalent Grades
Chemical Composition of Alloy Steel T5 Tubes
Mechanical Properties of Alloy Steel T5 Tubes
ASTM A213 T5 Alloy Steel Tubes Outside Diameter & Tolerances
Alloy Steel ASME SA213 T5 Tubes Wall thickness
Types & Forms of ASTM A213 T5 Tubes
Applications of ASTM A213 T5 Alloy Steel Seamless Tubes
Related Products
Frequently Asked Questions About Alloy Steel T5 Tubes

ASTM A213 T5 Alloy Steel Seamless Tubes Specifications

Our ASTM A213 T5 seamless tubes are manufactured to the highest standards, ensuring they meet the precise specifications required for critical high-temperature applications. Below are the key details regarding our tubes' dimensions, schedules, and forms.

Specification	ASTM A213 / ASME SA213
Dimensions	ASTM, ASME and API
Tubes Size	1/2″ OD up to 5″ OD, customs diameter also available
Schedule	SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type	Seamless
Form	Round, Square, Rectangular, Hydraulic Etc
Length	Single Random, Double Random & Cut Length.
Outer Diameter	6-2500mm; WT:1-200mm

Alloy T5 Tubes Equivalent Grades

Alloy Steel T5 tubes are widely recognized across international standards. This table provides the equivalent grades, which are essential for seamless use in global projects and specifications.

STANDARD	WERKSTOFF NR.	UNS
A213 T5	1.7362	K41545

Chemical Composition of Alloy Steel T5 Tubes

The chemical composition of Alloy Steel T5 is carefully balanced to provide its unique properties, including resistance to corrosion and high temperatures. The controlled percentages of chromium and molybdenum are key to its performance.

Element	Alloy T5 (%)
C, %	0.15 max
Mn, %	0.30-0.60
P, %	0.025 max
S, %	0.025 max
Si, %	0.50 max
Cr, %	4.00-6.00
Mo, %	0.45-0.65

Mechanical Properties of Alloy Steel T5 Tubes

Our Alloy Steel T5 tubes are manufactured to deliver superior mechanical properties, ensuring durability and reliability under stress. The values below represent the minimum tensile strength, yield strength, and elongation.

Element	Alloy Steel T5
Tensile Strength	415 min, MPa
Yield Strength	205 min, MPa
Elongation	30 % min

ASTM A213 T5 Alloy Steel Tubes Outside Diameter & Tolerances

Achieving the correct dimensions is crucial for any application. This table outlines the standard outside diameter and tolerance ranges for both hot-rolled and cold-drawn ASTM A213 T5 tubes.

Hot rolled	Outside Diameter, mm	Tolerance, mm
OD≤101.6		+0.4/-0.8
101.6＜OD≤190.5		+0.4/-1.2
190.5＜OD≤228.6		+0.4/-1.6

Cold Drawn	Outside Diameter, mm	Tolerance, mm
OD＜25.4		±0.10
25.4≤OD≤38.1		±0.15
38.1＜OD＜50.8		±0.20
50.8≤OD＜63.5		±0.25
63.5≤OD＜76.2		±0.30
76.2≤OD≤101.6		±0.38
101.6＜OD≤190.5		+0.38/-0.64
190.5＜OD≤228.6		+0.38/-1.14

Alloy Steel ASME SA213 T5 Tubes Wall thickness & Tolerance

The wall thickness and its tolerance are critical factors in the performance of pressure-rated tubes. This chart provides the standard tolerances for both hot-rolled and cold-drawn tubes based on their diameter and wall thickness.

Hot rolled	Outside Diameter, mm	Tolerance, %
OD≤101.6, WT≤2.4		+40/-0
OD≤101.6, 2.4＜WT≤3.8		+35/-0
OD≤101.6, 3.8＜WT≤4.6		+33/-0
OD≤101.6, WT>4.6		+28/-0

Cold Drawn	Outside Diameter, mm	Tolerance, %
OD≤38.1		+20/-0
OD>38.1		+22/-0

Length: 5800mm; 6000mm; 6096mm; 7315mm; 11800mm; 12000mm; and so on.

Max length: 16000mm, also U bending can be offered.

Types & Forms of ASTM A213 T5 Tubes

ASTM A213 T5 Seamless Tubes
ASTM A213 T5 Welded Tubes
ASTM A213 T5 ERW (Electric Resistance Welded) Tubes
ASTM A213 T5 EFW (Electric Fusion Welded) Tubes
ASTM A213 T5 Hydraulic Tubes
Forms: Round, Square, Rectangular

Applications of ASTM A213 T5 Alloy Steel Seamless Tubes

Heat Exchangers
Boilers
Superheaters
Refineries
Heaters & Reheaters
Power Plants
Petrochemical Industry

Frequently Asked Questions About Alloy Steel T5 Tubes

What is SA 213 T5 material?

SA213 T5 steel tubes are strong, corrosion-resistant, and flexible! SA213 T5 material has chromium, molybdenum, carbon, sulfur, manganese, phosphorus and silicon in the composition to give them strength similar to popular stainless steels 304 and 316. This unique blend makes them ideal for various applications.

What are ASTM A213 T5 Tubes used for?

ASTM A213 T5 tubes are a type of boiler tube specifically designed for high-pressure and high-temperature applications. They are commonly used in Power Plants, Refineries, Chemical Plants in various high-pressure and high-temperature chemical processes.

What are the benefits of ASTM A213 T5 Tubes?

ASTM A231 T2 offers several advantages like good strength, excellent T5 offers several advantages for these demanding applications like High-Temperature Strength, tubes can be welded using specialized welding techniques to create reliable joints and improved corrosion resistance compared to regular steel, helping them withstand the harsh environments found in power plants, refineries, and chemical facilities.

What are the limitations of ASTM A213 T5 Tubes?

Here are some factors to consider including Cost where T5 tubes are typically more expensive than regular steel tubes due to their specialized properties and Welding T5 tubes requires specific skills and expertise to ensure proper joint integrity.

Do you offer custom sizes or finishes for T5 Tubes?

We may be able to offer custom sizes and finishes for T5 tubes. However, due to their specialized nature, there might be limitations. Please provide details about your desired dimensions, tolerances, and surface finish requirements for an accurate quote.
