Inconel 600 Pipe Fittings and ASTM B366 UNS N06600 & Alloy 600 Fittings

Inconel 600 Pipe Fittings, ASTM B564 UNS N06600 Inconel 600 Fittings, Inconel Werkstoff Nr. 2.4816 Forged Fittings, Alloy 600 Buttweld Fittings, Inconel 600 Welding Outlet, Inconel 600 Socket Weld Outlet, Inconel 600 Nipple Outlet Manufacturer & Supplier In India

Solitaire Overseas is a leading manufacturer and supplier of high performance Inconel 600 Pipe Fittings also known as Alloy 600 UNS N06600 or Werkstoff Nr. 2.4816. It is a versatile structural engineering material, which is highly valued due to its high level of strength, stability, and longevity with the high temperature environments. It is specifically appreciated due to its greater levels of resistance to corrosion by hot chlorine gas and also due to its power to oppose oxidizing and scaling up to 980 o C. This renders these fittings essential in the furnace and heat-treating industries as well as nuclear industries specifically for steam generator boiling and primary water piping systems.

Alloy 600 mechanical properties are remarkable, and its mechanical properties have a minimum tensile strength of 655 Mpa and the minimum yield strength of 310 Mpa. These fittings have a wide thermal range, cryogenic to 700 o C (370 o F). It is important to note that Inconel 600 does not need any age-hardening treatment, but it is only strengthened and hardened by cold working. Having a high melting point of about 1413C and maximum elongation capacity of 40 percent, the components have a long working life but are very easy to work and ductile.

Regarding fabrication and machining, Inconel 600 Buttweld Fittings can be produced via both hot and cold rolling processes. Major hot working should be performed between 2300°F and 1850°F, ensuring the use of low-sulfur reducing furnace atmospheres during forging. While the material is easy to bend and weld—commonly using gas tungsten arc or electron beam welding—it does exhibit a characteristic "gumminess" and work-hardening tendency during machining that distinguishes it from standard steels.

As a leading supplier, we provide a comprehensive range of ASTM B564 forged fittings and buttweld outlets, including welding, socket weld, and nipple outlets. These are available in various sizes and thicknesses, ranging from Schedule 5 to Schedule 160, as well as Schedule XXS. Our commitment is to provide top-tier, precision-engineered products at feasible, competitive rates for global industrial applications.

Looking to buy Stainless Steel Fittings?

Check price of Stainless Steel 304 Fittings and Stainless Steel 316 Fittings

Weight Calculator

Inconel 600 Pipe Fittings Specification
Chemical Composition of Inconel 600 Fittings
Inconel 600 Pipe Fittings Mechanical Properties
Equivalent Grades of UNS N06600 Fittings
Alloy 600 Fittings Weight Chart
Dimensions Standard of ASME SB366 Alloy 600 Fittings
Inconel 600 Welded Fittings Heat Treatment
Inconel 600 Fittings Melting Point
Inconel 600 Pipe Fittings HS Code
Types of Inconel 600 Pipe Fittings
Applications of Inconel 600 Fittings
Supplier of Inconel 600 Pipe Fittings Products
Related Products

Inconel 600 Pipe Fittings Specification

These fittings are manufactured to rigorous industry standards, ensuring material integrity, dimensional accuracy, and suitability for high-performance applications across various sectors.

Specification	ASTM B366, ASTM SB 366, ASTM B564, ASME SB564
Dimensions	ANSI/ASME B16.9, B16.28, MSS-SP-43.
Size	½”NB to 24″NB in Sch 10s, 40s, 80s, 160s, XXS.
Thickness	Sch Sch 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160 Sch XXS
Types	Seamless / ERW / Welded / Fabricated
Grades	Inconel 600 – UNS N06600, Inconel 601 – UNS N06601 Inconel 625 – UNS N06625 Incoloy 800 – UNS N08800, Incoloy 800H / HT – UNS N08810, Incoloy 825 – UNS N08825

Chemical Composition of Inconel 600 Fittings

The high nickel content, combined with chromium, provides Inconel 600 (UNS N06600) with its remarkable resistance to corrosion and excellent performance in elevated temperature service.

Element	Composition (%)
Ni	72.0 min
Cr	14.0 – 17.0
Fe	6.0 – 10.0
C	0.15 max
Mn	1.00 max
Si	0.50 max
S	0.015 max
Cu	0.50 max

Inconel 600 Pipe Fittings Mechanical Properties

These mechanical properties define the structural integrity of the fittings, allowing them to withstand significant stress and operate reliably at high temperatures, critical for nuclear and furnace applications.

Property	Value
Tensile Strength	550 MPa (min)
Yield Strength (0.2% offset)	240 MPa (min)
Elongation	30% (min)
Hardness	Rockwell B 85 (max)
Operating Temperature Range	Up to 1093°C (2000°F)

Equivalent Grades of UNS N06600 Fittings

The table provides common equivalent designations for UNS N06600 (Inconel 600) across different international and regional standards, simplifying material selection for global projects.

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
Inconel 600	2.4816	N06600	NCF 600	NA 13	МНЖМц 28-2,5-1,5	NC15FE11M	NiCr15Fe

Alloy 600 Fittings Weight Chart

Consult this table for the approximate weight data of Alloy 600 Fittings, which is essential for calculating shipping costs, pipe support requirements, and overall system load design.

Product range and theoretical weights (kg)
DN	Schedule 10S			Schedule 40S			Schedule 80S
DN	900 Elbow	450 Elbow	Equal tee	900 Elbow	450 Elbow	Equal tee	900 Elbow	450 Elbow	Equal tee
8	0.02	0.01	0.03	0.03	0.02	0.06	0.04	0.03	0.07
10	0.03	0.02	0.05	0.03	0.02	0.03	0.06	0.04	0.09
15	0.06	0.03	0.09	0.08	0.04	0.10	0.10	0.05	0.14
20	0.07	0.03	0.13	0.08	0.04	0.17	0.11	0.05	0.20
25	0.14	0.08	0.28	0.15	0.11	0.29	0.22	0.14	0.38
32	0.23	0.11	0.49	0.26	0.17	0.59	0.40	0.23	0.68
40	0.30	0.17	0.68	0.40	0.23	0.86	0.51	0.29	1.02
50	0.50	0.25	0.85	0.70	0.4	1.28	0.91	0.59	1.59
65	0.85	0.48	1.41	1.40	0.77	2.19	1.81	0.99	3.13
80	1.25	0.63	1.77	2.20	1.08	3.31	2.97	1.50	4.45
90	1.70	0.75	2.67	2.83	1.42	4.08	4.00	2.00	5.44
100	2.10	1.08	3.46	4.47	2.09	5.27	6.18	2.81	7.71
150	5.45	2.72	8.07	10.89	5.44	10.99	16.32	8.16	13.61
200	10.20	5.33	15.65	21.54	10.77	20.91	33.11	16.56	28.12
250	18.15	9.75	26.46	38.56	19.27	35.38	51.71	25.86	49.90
300	25.80	13.62	39.46	59.42	29.71	62.14	79.38	39.69	83.91

Product range and theoretical weights (kg)
DN	Schedule 10S			Schedule 40S			Schedule 80S
DN	Con reducer	Ecc reducer	Reducing tee	Con reducer	Ecc reducer	Reducing tee	Con reducer	Ecc reducer	Reducing tee
40x.25	0.19	0.19	0.60	0.26	0.26	0.76	0.34	0.34	0.90
50x25	0.28	0.28	0.73	0.40	0.40	1.10	0.54	0.54	1.37
50x40	0.31	0.31	0.76	0.45	0.45	1.15	0.59	0.59	1.43
80x.50	0.55	0.55	1.56	1.00	1.00	2.91	1.79	1.79	3.91
100x50	0.78	0.78	2.94	1.50	1.50	4.48	1.95	1.95	6.55
100x80	0.87	0.87	3.04	1.74	1.74	4.64	2.33	2.33	6.79
150x80	1.82	1.82	6.86	3.95	3.95	9.68	5.51	5.51	11.57
150x100	1.96	1.96	7.10	4.07	4.07	11.94	5.96	5.96	11.97
200x100	3.01	3.01	13.46	6.55	6.55	17.98	9.23	9.23	24.18
200x150	3.19	3.19	14.08	6.74	6.74	18.82	10.12	10.12	25.31

Dimensions Standard of ASME SB366 Alloy 600 Fittings

The dimensions provided here adhere to the ASME SB366 standard, ensuring that these Alloy 600 fittings will precisely align and integrate with standard pipes and system components.

Nominal Pipe Size (inches)	Outside Pipe Diameter (inches)	Distance Center to End (inches)
Nominal Pipe Size (inches)	Outside Pipe Diameter (inches)	90o Elbows	45o Elbows
1	1.315	1 1/2	7/8
1 1/4	1.660	1 7/8	1
1 1/2	1.900	2 1/4	1 1/8
2	2.375	3	1 3/8
2 1/2	2.875	3 3/4	1 3/4
3	3.5	4 1/2	2
3 1/2	4.0	5 1/4	2 1/4
4	4.5	6	2 1/2
5	5.563	7 1/2	3 1/8
6	6.625	9	3 3/4
8	8.625	12	5
10	10.750	15	6 1/4

Inconel 600 Welded Fittings Heat Treatment

Proper heat treatment is crucial for optimizing the corrosion resistance and mechanical properties of Inconel 600 Welded Fittings. Annealing typically restores ductility and uniformity to the material.

Condition	Type	Cooling	Temperature	Time
Annealed	Stress Relieve	Air	500 – 700°F (260 – 370°C)	0.5 – 1hr

Inconel 600 Fittings Melting Point

The high melting range of Inconel 600 Fittings (1354∘C−1413∘C) underpins their excellent thermal stability and makes them suitable for extreme high-temperature applications like furnace components.

1354-1413°C
2470-2575 °F

Inconel 600 Pipe Fittings HS Code

HSN Code	Product Description
7507	Inconel 600 Pipe Fittings, tubes and pipes and tube or (for example, couplings, elbows, sleeves)

Types of Inconel 600 Pipe Fittings

We offer a diverse inventory of Inconel 600 Pipe Fittings to satisfy both buttweld and high-pressure threaded/socket weld requirements.

Inconel 600 Pipe Elbow

Inconel 600 Pipe Tee

Inconel 600 Pipe Reducer

Inconel 600 Pipe End Cap

Inconel 600 Threaded Fittings

Inconel 600 Cap

Inconel 600 Bushing

Inconel 600 Plug

Inconel 600 Union

Inconel 600 Hex Nipple

Inconel 600 Street Elbow

Inconel 600 Adapter

Applications of Inconel 600 Fittings

Chemical Processing: Used in fittings (pipes, valves, pumps) for handling acids, organic compounds, and alcohols in extremely corrosive, high-temperature environments.
Aerospace Industry: Manufactures components like core engine parts, jet engines, and rocket motors. The alloy withstands high pressure, extreme temperature, and is used for parts needing high thermal stability (e.g., insulation shields).
Furnace Components: Used for fabricating parts exposed to high heat, such as muffles, chambers, and tops. Essential for high-temperature heat treatment processes (annealing, hardening).
Nuclear Power Plants: Ideal for components exposed to severe radiation, high temperatures, and corrosive environments due to its resistance to oxidation.
Marine Applications: Used for marine fittings (valves, pumps, heat exchangers) due to its ability to withstand saltwater, marine organisms, and other corrosive substances.

Supplier of Inconel 600 Pipe Fittings Products

We are a leading Supplier, Exporter, and Stockholder of a comprehensive range of Inconel 600 Pipe Fittings, catering to industrial demand globally with various grades and types.

Inconel 600 Pipe Fittings
600 Inconel Seamless Pipe Fittings
Inconel UNS N06600, N06601 Pipe Elbow
600 Inconel Buttweld Reducer
Inconel 600 Stubends Dealer
Inconel 600 U Bend Stockholder
Inconel UNS N06600 45deg.Elbow
DIN 2.4816, 2.4851 Inconel Pipe Tee
Inconel 600 Buttweld Reducing Nipple
600 Inconel Long Radius Bend
ASTM B366 Inconel 600 Swage Nipple
Inconel 600 Buttweld Pipe Fittings
600 Inconel Welded Pipe Fittings
Inconel 600 Buttweld Tee
600 Inconel Buttweld Pipe Bend
Inconel 600 Pipe Fittings Exporter
600 Pipe End Cap Distributors
600 Inconel 90deg. LR Elbow Manufacturer
DIN 2.4856, 2.4668 Inconel Cross Tee
Inconel 600 Short Radius Elbow
600 End Pipe Cap Stockist
ASME SB366 Inconel 600 Pipe Nipple

Inconel 600 Fittings Latest Price List

To receive the latest Alloy 600 Fittings Price List, please contact our sales team at +91-9619103479 or send your requirements via email to vishal@solitaire-overseas.com .

Description	Price In INR (Per KG)
Inconel 600 Concentric Reducer
3/4 X 1/2 X SCH 160	789.00
1 X 1/2 X SCH 160	1035.00
4 X 2 X SCH 80 X SCH 160	1698.00
6 X 4 X SCH 80	2365.00
8 X 4 X SCH 160	3465.00
Inconel 600 Elbow
2" X SCH 40	1200.00
3" X SCH 40	1898.00
4" X SCH 40	2509.00
6" X SCH 40	3865.00
8" X SCH 40	4968.00
Inconel 600 Equal Tee
3/4 X 40	900.00
1/2 X 40	587.00
2" X 40	1798.00
4" X 40	2999.00
6" X 40	3609.00

Frequently Asked Questions About Inconel 600 Fittings

What is Inconel 600?

Inconel 600 is a nickel-chromium alloy, also known by the designation UNS N06600 or W.Nr. 2.4816. It is known for its excellent corrosion resistance and high strength, especially at elevated temperatures.

What standards are Inconel 600 fittings made to?

Inconel 600 fittings are typically made to ASTM B366 (Wrought Fittings) and ASME B16.9 (Factory-Made Wrought Butt-welding Fittings) or ASME B16.11 (Forged Fittings). The material designation is ASTM B366 UNS N06600.

What types of Inconel 600 fittings are available?

Common types of Inconel 600 fittings include elbows (long radius, short radius), tees (equal, reducing), reducers (concentric, eccentric), stub ends, return bends, caps, and forged fittings like couplings, unions, and plugs.

What applications are Inconel 600 fittings used in?

Inconel 600 fittings are used in environments demanding resistance to extreme heat and corrosion, such as chemical processing, aerospace components, thermal wells, boiler parts, nuclear engineering, and equipment handling highly reactive chemicals.

Can Inconel 600 fittings be used at high temperatures?

Yes, Inconel 600 is specifically designed for service at high temperatures. It exhibits high resistance to oxidation and scaling and maintains its mechanical properties, including rupture strength, even after prolonged exposure to elevated heat.
