Alloy 800 Pipe Fittings, Inconel 1.4876 Pipe Fittings, ASTM B366 Incoloy 800H Pipe Fittings, Incoloy N08811 Pipe Fittings, Incoloy 800HT Seamless Pipe Fittings, Nickel Alloy 800 Pipe Fittings, Incoloy 800H Butt weld Fittings and Incoloy 800HT Butt weld Fittings Suppliers in India

Solitaire Overseas is a well-recognized and leading exporter of premium-quality ferrous and non-ferrous products in today’s competitive market. We are widely known for supplying Incoloy 800HT Pipe Fittings in a variety of shapes and sizes, and we are also a trusted importer of Inconel fittings in multiple grades.

What Are Inconel 800 Fittings?

Inconel 800 fittings are industrial-grade pipe components made from the nickel-iron-chromium alloy UNS N08800, along with its enhanced high-carbon variants, Inconel 800H (UNS N08810) and Incoloy 800HT (UNS N08811). These fittings are specifically engineered to join pipes and their components, primarily functioning to change the direction of fluid flow within a system. They are the preferred choice for high-temperature process systems due to their ability to withstand prolonged exposure to elevated temperatures, thermal cycling, and corrosive environments.

The Incoloy 800HT grade is an enhanced version of Alloy 800, distinguished by modifications made to tightly control carbon content. It achieves this control through small additions of titanium and aluminum. This careful alloying yields superior mechanical characteristics, including excellent workability, weldability, fabricability, and formability, along with high performance, durability, and reliability. These properties make 800HT widely used in various demanding manufacturing and construction applications.

We offer Inconel 800 Buttweld Fittings and a comprehensive range of other types, including elbows, tees, bends, reducers, couplings, and crosses. These are available with various connection ends, such as buttweld, socket weld, threaded, and flanged. Our fittings are supplied in a wide selection of dimensions, diameters, thicknesses, standards, and finishes, ensuring precise customization to meet the specific requirements of our customers.

Enquire Now

Inconel 800 Fittings Specification
Equivalent Grades of Inconel 800 Fittings
Chemical Composition of Nickel Alloy 800 Pipe Fittings
Mechanical Properties of Inconel 800 Buttweld Fittings
Dimensions Standard of Inconel 800 Fittings
Weight Chart of Incoloy 800 Fittings
Incoloy Alloy 800 Fittings Pressure Rating
Incoloy 800 Pipe Fittings HSN Code
Incoloy 800 Pipe Fittings Types
Applications of Incoloy 800 Fittings

Inconel 800 Fittings Specification

Category	Specification Details
Specification	ASTM B366 / ASME SB366
Standard	EN, ISO, DIN, JIS, NPT
Dimension Standard	ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Size	1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM A403 Grade WP317L Pipe Fitting
Type	Seamless / Welded / Fabricated
Pressure-Temperature Class	150LB, 300LB, 600LB, 1500LB, 2500LB.
Schedule	Schedule 5 TO Schedule XXS.
Type Of Dimension	BS1640, EN 10253 - 4, DIN 2605, JIS B2312, ANSI B16.9, MSS SP-75, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2313

Equivalent Grades of Inconel 800 Fittings

STANDARD	WERKSTOFF NR.	UNS	GOST	AFNOR	JIS	BS	EN	OR
Incoloy 800	1.4876	N08800	ЭИ670	Z8NC32-21	NCF 800	NA 15	X10NiCrAlTi32-20	XH32T
Incoloy 800H	1.4958 / 1.4876	N08810	ЭИ670	Z8NC33-21	NCF 800H	NA 15(H)	X5NiCrAlTi31-20	XH32T
Incoloy 800HT	1.4859 / 1.4876	N08811	ЭИ670	-	NCF 800HT	NA 15(HT)	X8NiCrAlTi32-21	XH32T

Chemical Composition of Nickel Alloy 800 Pipe Fittings

Grade	C	Mn	Si	S	Cu	Fe	Ni	Cr	Al	Ti
800	0.10 max	1.50 max	1.00 max	0.015 max	0.75 max	39.50 min	30.00 – 35.00	19.00 – 23.00	0.15 – 0.60	0.15 – 0.60
800H	0.05 – 0.10	1.50 max	1.00 max	0.015 max	0.75 max	39.50 min	30.00 – 35.00	19.00 – 23.00	0.15 – 0.60	0.15 – 0.60
800HT	0.06 – 0.10	1.50 max	1.00 max	0.015 max	0.75 max	39.50 min	30.00 – 35.00	19.00 – 23.00	0.15 – 0.60	0.15 – 0.60

Mechanical Properties of Inconel 800 Buttweld Fittings

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Alloy 800 / 800H / 800HT	7.94 g/cm3	1385 °C (2525 °F)	Psi – 75,000 , MPa – 520	Psi – 30,000 , MPa – 205	30 %

Dimensions Standard of Inconel 800 Fittings

Nominal Pipe Size	Outside Diameter		Caps	Straight Tees	Straight Crosses	Stub Ends
inch	mm	inch	Length (inch)	Center to End (inch)	Center to End (inch)	Lap Diameter (inch)	Long Length (inch)	Short Length (inch)
1/2	21.3	0.840	1	1	–	1 3/8	3	2
3/4	26.7	1.050	1	1 1/8	–	1 11/16	3	2
1	33.4	1.315	1 1/2	1 1/2	1 1/2	2	4	2
1 1/4	42.2	1.660	1 1/2	1 7/8	1 7/8	2 1/2	4	2
1 1/2	48.3	1.900	1 1/2	2 1/4	2 1/4	2 7/8	4	2
2	60.3	2.375	1 1/2	2 1/2	2 1/2	3 5/8	6	2 1/2
2 1/2	73.0	2.875	1 1/2	3	3	4 1/8	6	2 1/2
3	88.9	3.500	2	3 3/8	3 3/8	5	6	2 1/2
3 1/2	101.6	4.000	2 1/2	3 3/4	3 3/4	5 1/2	6	3
4	114.3	4.500	2 1/2	4 1/8	4 1/8	6 3/16	6	3
5	141.3	5.563	3	4 7/8	4 7/8	7 5/16	8	3
6	168.3	6.625	3 1/2	5 5/8	5 5/8	8 1/2	8	3 1/2
8	219.1	8.625	4	7	7	10 5/8	8	4
10	273.1	10.750	5	8 1/2	8 1/2	12 3/4	10	5
12	323.9	12.750	6	10	10	15	10	6

Weight Chart of Incoloy 800 Fittings

DN	Schedule 10S			Schedule 40S			Schedule 80S
	900 Elbow	450 Elbow	Equal tee	900 Elbow	450 Elbow	Equal tee	900 Elbow	450 Elbow	Equal tee
8	0.02	0.01	0.03	0.03	0.02	0.06	0.04	0.03	0.07
10	0.03	0.02	0.05	0.03	0.02	0.03	0.06	0.04	0.09
15	0.06	0.03	0.09	0.08	0.04	0.10	0.10	0.05	0.14
20	0.07	0.03	0.13	0.08	0.04	0.17	0.11	0.05	0.20
25	0.14	0.08	0.28	0.15	0.11	0.29	0.22	0.14	0.38
32	0.23	0.11	0.49	0.26	0.17	0.59	0.40	0.23	0.68
40	0.30	0.17	0.68	0.40	0.23	0.86	0.51	0.29	1.02
50	0.50	0.25	0.85	0.70	0.4	1.28	0.91	0.59	1.59
65	0.85	0.48	1.41	1.40	0.77	2.19	1.81	0.99	3.13
80	1.25	0.63	1.77	2.20	1.08	3.31	2.97	1.50	4.45
90	1.70	0.75	2.67	2.83	1.42	4.08	4.00	2.00	5.44
100	2.10	1.08	3.46	4.47	2.09	5.27	6.18	2.81	7.71
150	5.45	2.72	8.07	10.89	5.44	10.99	16.32	8.16	13.61
200	10.20	5.33	15.65	21.54	10.77	20.91	33.11	16.56	28.12
250	18.15	9.75	26.46	38.56	19.27	35.38	51.71	25.86	49.90
300	25.80	13.62	39.46	59.42	29.71	62.14	79.38	39.69	83.91
